Huawei OLT Configuration



Table of Contents

Step 1 : Access huawei olt default ip address

In this step, we will connect our computer to Huawei olt via telnet. By default, Huawei OLT has a default IP address 10.11.104.2. To access IP we need to connect an ethernet cable from the computer to the Huawei olt ETH port. At the command line interface, you will find this port named meth0.

Step 2 : Access huawei olt default ip address



ETH port is designed only for management; you can’t use this port for passing traffic to customers. This ETH port is isolated from other ports.

After connecting cable from ETH port to

Computer need to change computer IP to 10.11.104.1 255.255.255.0

Step 3 : Access huawei olt default ip address



Now you can reach the IP address 10.11.104.2. Using ping command from pc we can make sure the connectivity

Ping 10.11.104.1

Now will log in to olt via telnet using putty software

User name: root

User password: admin or admin123

MA5608T>

MA5608T> enable

MA5608T#config
